Welding Fixture Design Project

• Grid weldment: Rotary indexing fixture for tack welding and finish welding.

  Concept/ layout design (location, orientation, clamping and indexing positions).

  Hydraulic cylinders selection and other standard fixture elements selection.

  Manufacturing feasibility (loading/ unloading & access to weld positions).

  Final 3D models and 2D drawings for manufacturing.

  BOM for custom parts and standard parts including hydraulic components.

Value Add

• Ease of loading/ unloading

  Ease of welding

  Overall cost reduction
