Impulse Testing Fixture design & development

Impulse load test condition on Chassis/ Frame weldment:

• Hydraulic cylinder mounting interface.

  Indexing plate to mount and rotate Chassis/ Frame weldment portion (ideal physical model) which subjects to hydraulic cylinder impulse loads.

  Indexing mounting positions to simulate actual loading condition of boom and boom lift cylinder angles.

  Mounting interfaces for hydraulic components such as valve block, hydraulic hoses, etc.,

Value Add

• Ease of loading/ unloading

  Overall test cost reduction
